VGMetrology

What is VG Metrology?

VG Metrology is a comprehensive metrology solution that allows users to perform dimensional measurements and geometric tolerancing on CT data. Users can measure features such as distances, angles, diameters, radii, and form deviations, as well as apply GD&T (geometric dimensioning and tolerancing) standards to evaluate the conformity of parts and assemblies. VG Metrology also supports importing and exporting CAD models and aligning them with CT data for direct comparison and deviation analysis. VG Metrology is a powerful tool for quality assurance and inspection of complex and internal structures that are difficult or impossible to measure with conventional methods.

Key Features:

• Full-featured. VGMETROLOGY offers you the full metrology-related functionality of VGSTUDIO MAX including GD&T functionality.
• Uncompromisingly accurate. VGMETROLOGY gives you the complete picture of all object surfaces – and saves it in the very compact .mvgl format.
• Universal. VGMETROLOGY works natively on voxel, point cloud, mesh, and CAD data.
• Easy-to-use. The focused range of functionality makes VGMETROLOGY easily accessible for new users.
• Seamless. You can exchange files between VGMETROLOGY and other Volume Graphics products of the same generation.
• Affordable. VGMETROLOGY costs significantly less than a comparably equipped VGSTUDIO MAX.

The Volume Graphics Metrology Kernel in VGMETROLOGY (Windows 64 bit) has been verified by the Physikalisch- Technische Bundesanstalt (PTB).*

*PTB (Germany’s national metrology institute) tested the algorithms based on the minimum-zone method (“Chebyshev”) and on the least-squares method (“Gauss”). These algorithms are used for coordinate measurement in VGMETROLOGY.
