The Home Of Computed Tomography
OR3D CT provides high-quality X-ray computed tomography (CT) scanning services and solutions for various industries and applications. With a range of CT scanners from RX Solutions, a leading manufacturer of industrial CT systems, that can handle objects of different sizes, shapes, materials, and densities we can scan objects from 0.4 microns to 800 mm in resolution, and from 1 gram to 300 kg in weight.
We perform different types of scans such non-destructive testing (NDT) scans that can reveal internal defects, cracks, voids, porosity, inclusions, and other anomalies that are not visible to the naked eye. We can also perform dimensional metrology scans that can measure and compare the dimensions, shapes, and geometries of objects with high accuracy and precision.
Post Processing
OR3D CT can deliver the results and solutions of the scans in various formats, such as 2D images, 3D images, videos, animations, reports, and certificates. OR3D CT can also provide post-processing and analysis services, such as segmentation, meshing, surface extraction, volume calculation, porosity analysis, defect analysis, wall thickness analysis, deviation analysis, and many more.
A porosity is usually an air gap or bubble within a part. Porosities are often unwanted and found commonly in injection moulded or cast parts. A porosity can often be seen as a dark area on a CT slice.
A nominal actual comparison, sometimes referred to as a 3D compare, is a way of showing and analysing the differences between a reference and a measured object.
Foam structure analysis is used to better understand and visualise a foam like structure. It can be used to analyse the cell shape, size and distribution as well as the struts which separate the cells.
Segmentation is the process of virtually separating different parts or materials from a CT (computed tomography) scan.
After an accurate surface has been determined, it is possible to calculate the localised wall thickness on part. A wall thickness can be calculated on mesh and volume objects.
Digital radiography (DR), is a fast and efficient way to produce high-quality 2D images of objects.
